Features:
Integration,standard 86 type direct wall mounted.
eek cycle,six period one day the temperature vary according to temperature program design.
Sensor selection:Internal single sensor controller,External sensor controller.
Child lock function.
Temperature sensor failure alarm.
Sensor selection,rest day selection,highest limit temperature,lowest limit temperature,preheating heating,
temperature correction
Technical Data
| Measure range: 0~40 Celsius | 3A 10A 16A |
| Temperature control Accuracy :+/-1 Celsius | WST11.H1 Water heating,3A |
| Power supply: 85-250VAC 50/60Hz | WST11.H2 Electric warming,10A |
| Power consumption:<1W | WST11.H3 Electric warming,16A |
| Sensor type:NTC B=3380 10K@25Celsius | Sensor Q'TY:2 PCS |
| Multi. periods programe (5+2/6+1/7) | Large LCD display + back lighting |
| Mount height:1.5meter | DIMENSIONS: 86x86X12mm |
| Control mode:heating | WEIGHT:170G/PCS |
| Body material: Antiflaming PC | White box size: 100x100X60mm |
| CE | Carton size: 53x33x22cm/50pcs |
Diagram
