Compact High-performance Fan Heater CS 130 950W,1200w

Compact High-performance Fan Heater CS 130 950W,1200w
Compact High-performance Fan Heater CS 130 950W,1200w

Compact High-performance Fan Heater CS 130 950W,1200w

● Compact design

● High heating performance

● Double insulated

● Integrated thermostat(optional)

● Optional clip or screw fixing

The compact high performance fan heater prevents formation of condensation and provides an evenly distributed interior air temperature in enclosures with electric/electronic components.

The plastic enclosure provides double insulation and acts as protection against contact.

The fan heater is available with optional integrated thermostat for temperature control.

The CS 130 was designed as a stationary unit for wall fixing.

For fixing on the bottom of the enclosure the fanheater CS 030 is recommended.



Technical Data

Heating element

PTC resistor - temperature limiting

Temperature safety cut-out

to protect against overheating in case of fan failure

Axial fan, ball bearing

service life 50,000h at 25°C (77°F)

Connection

2-pole max. 2.5mm², clamping screw with strain relief, torque 0.8Nm max.

Casing

plastic according to UL94 V-0, black

Mounting

clip for 35mm DIN rail, EN 60715

Fitting position

 horizontal

Dimensions

182 x 160 x 142mm

Weight

approx. 1.25kg

Operating / Storage temperature

-45 to +70°C (-49 to +158°F)

Protection type / Protection class

IP20 / II (double insulated)

Art. No.

Model

Operating voltage

Heating capacity1)

Inrush current max.

Setting range

13060.0-00

Fan Heater with thermostat

230VAC, 50/60Hz

1,200W

13A

0 to +60°C

13060.0-01

Fan Heater without thermostat

230VAC, 50/60Hz

1,200W

13A

-

13060.9-00

Fan Heater with thermostat

120VAC, 50/60Hz

1,200W

16A

+32 to +140°F

13060.9-01

Fan Heater without thermostat

120VAC, 50/60Hz

1,200W

16A

-

*at 20°C (68°F)ambient temperature
