Aluminum lugs longitudinally DL Application Inside&outside MV and LV terminations for Wide range copper cables. Grounding. Description The lug is made of electrolutic aluminum and longitudinally sealed. To be crimped by hexagonal technic. Specially made for high current
| Cat No | Conductor cross section | Conductor diameter (mm) | Flat hole diameter mm |
Diamesion mm | |||||
| re/rm/sm mm2 | VDE0295 | DIN 48201/1 | D | d | L | L1 | B | ||
| DT-10 DT-16 DT-25 DT-35 DT-50 DT-70 DT-95 DT-120 DT-150 DT-185 DT-240 DT-300 DT-400 DT-500 DT-630 DT-800 |
10 16 25 35 50 70 95 120 150 185 240 300 400 500 630 800 |
5.6-6.5 6.6-7.5 7.7-8.6 9.3-10.2 11.0-12.0 12.5-13.5 13.9-15.0 15.5-16.8 17.8-19.2 20.0-21.6 22.9-24.6 25.7-27.6 29.3-32.5 |
4.1 5.1 6.3 7.5 9.0 10.5 12.5 14.0 15.7 17.5 20.2 22.5 26.0 29.1 32.6 36.8 |
8.5 8.5 8.5 10.5 10.5 12.5 12.5 14.5 14.5 16.5 16.5 18 21 21 21 21 |
10 11 12 14 16 18 21 23 25 27 30 34 38 45 50 65 |
5.3 6.5 7 8.5 9.8 11.5 13.5 15 17 19 21 23.5 26.5 29.2 32 38 |
66 70 75 83.5 94 102 112 118 128 133 140 165 178 200 220 250 |
31 32 36 40 42 46 48 52 54 58 61 67 76 85 90 100 |
8.5 8.5 8.5 10.5 10.5 12.5 12.5 14.5 14.5 16.5 16.5 21 21 21 21 21 |
