| OUTPUT | ||||
| Model | MDR-10-5 | MDR-10-12 | MDR-10-15 | MDR-10-24 |
| DC Voltage | 5V | 12V | 15V | 24V |
| Rated Current | 2A | 0.84A | 0.67A | 0.42A |
| Current Range | 0-2A | 0-0.84A | 0-0.67A | 0-0.42A |
| Rated Power | 10W | 10W | 10W | 10W |
| Ripple & Noise | 80mVp-p | 120mVp-p | 120mVp-p | 150mVp-p |
| Voltage Tolerance | ±5% | ±3% | ±3% | ±1% |
| Line regulation | ±1.0% | ±1.0% | ±1.0% | ±1.0% |
| Load regulation | ±5.0% | ±3.0% | ±2.0% | ±2.0% |
| Setup, Rise Time | 500ms,30ms/230VAC 1000ms,30ms/115VAC at full load | |||
| Hold Up Time | 120ms/230VAC 25ms/115VAC at full load | |||
| INPUT | ||||
| Voltage Range | 85~264VAC 47~63Hz; 120~370VDC | |||
| AC Current | 0.33A/115VAC 0.21A/ 230VAC | |||
| Efficiency | 77% | 81% | 81% | 84% |
| Inrush Current | Cold start 35A/115V 70A/230V | |||
| Leakage Current | <1mA/240VAC | |||
| PROTECTION | ||||
| Over Load | Above 105% rated output power | |||
| Protection type: Hiccup mode, recovers automatically after fault condition is removed | ||||
| Over Voltage | 5.75-6.75V | 13.8-16.2V | 17.25-20.25V | 27.6-32.4V |
| Protection type: Shut down o/p voltage, re-power on to recover | ||||
| ENVIRONMENT | ||||
| Working Temp., Humidity | -20℃~+70℃; 20%~90% RH non-condensing | |||
| Storage Temp., Humidity | -40℃~+85℃; 10%~95%RH | |||
| Temp. Coefficient | ±0.03%/℃(0~50℃) | |||
| Vibration | 10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes | |||
| SAFETY | ||||
| Withstand Voltage | I/P-O/P: 3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | |||
| Isolation Resistance | I/P-O/P, I/P-FG, O/P-F/G: 100M Ohms / 500VDC/25℃/70% RH | |||
| STANDARD | ||||
| Safety Standard | Design refer to UL508,TUV EN60950-1 | |||
| EMC Standard | Design refer to EN55011,EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,EN55024,EN61000-6-1，EN61204-3, light industry level, criteria A | |||
| OTHERS | ||||
| Dimension | 22.5*90*100mm(W*H*D) | |||
| Weight | 0.17Kg | |||
| Packing | 72pcs/carton/13.2kg/0.91CUFT | |||
