· Ultra-thin design, saving installation space
· Protection type: short circuit/overcurrent
· Working efficiency up to 88%
· 100% full load aging test
|
Model
|
|
WDP-100-12
|
WDP-100-15
|
WDP-100-24
|
WDP-100-36
|
WDP-60-48
|
|
Output characteristic
|
Dc output voltage
|
12V
|
15V
|
24V
|
36V
|
48V
|
|
Rated current
|
7.5A
|
6.5A
|
4.2A
|
2.7A
|
2.1A
|
|
|
Current range
|
0-7.5A
|
0-6.5A
|
0-4.2A
|
0-2.7A
|
0-2.1A
|
|
|
Rated power
|
9OW
|
97W
|
100W
|
100W
|
100W
|
|
|
Ripple & Noise(Max)
|
150mVp-p
|
150mVp-p
|
200mVp-P
|
220mVp-p
|
240mVp-p
|
|
|
Voltage regulationr ange
|
10.9-13.2V
|
13.6-16.5V
|
21.8-26.4V
|
32.7-39.6V
|
43.6-52.8V
|
|
|
Voltage accuracy
|
±1%
|
±1%
|
±1%
|
±1%
|
±1%
|
|
|
Linear adjustmentr ate
|
±1%
|
±1%
|
±1%
|
±1%
|
±1%
|
|
|
Load adjustment rate
|
±1%
|
±1%
|
±1%
|
±1%
|
±1%
|
|
|
Start & rise time
|
2000mS，30mS/115VAC(Full load):1000ms，30mS/230VAC
|
|||||
|
Holding time
|
30mS/230VAC(Full load)10mS/115VAC(Full load)
|
|||||
|
Input characteristic
|
Input voltage
|
85-264VAC 120-370VDC
|
||||
|
Input frequency
|
47-63Hz
|
|||||
|
efficiency
|
87%
|
87%
|
88%
|
88%
|
88%
|
|
|
Input current
|
3A/115VAC 1.61230VAC
|
|||||
|
Power factor
|
