Features
1.Professional manufacturer
2.high quanlity.
3.The price of competitive
Specification
|
Model |
WST-800 |
WST -1000 |
|
|
input |
Dc voltage |
12V/24V/48V/110V |
|
|
Voltage range |
10-15VDC/20-31VDC/40-60VDC/96-127VDC |
||
|
No-load current |
<0.9 |
||
|
Efficiency |
>85% |
||
|
DC connection |
Wiring nose |
||
|
output |
output voltage |
100/110/120VAC/220/230/240VAC |
|
|
Rated power |
800w |
1000w |
|
|
Instantaneous power |
1600w |
2000w |
|
|
Output waveform |
Pure sine wave |
||
|
Frequency |
50HZ/60HZ |
||
|
Waveform distortion |
3% |
||
|
Protect |
Low pressure alarm |
10.5DC±0.5V/21DC±1V/42VDC±1V/100VDC±1V |
|
|
Low Voltage Shut Down |
10DC±0.5V/20DC±1V/40VDC±1V/96VDC±5V |
||
|
cutting-out |
The output automatically shut down |
||
|
overload |
Output shut down |
||
|
overpressure |
15.5V/30.5V/61.2V/120V |
||
|
overheating |
The output automatically shut down |
||
|
The environment |
Working temperature |
-10°c-50°c |
|
|
Working humidity |
20%-90% |
||
|
Storage temperature |
-30°c-70°c |
||
|
Packing |
Machine Size |
300*165*85 |
335*165*85 |
|
Packing size |
400*230*148 |
430*230*148 |
|
|
Net weight |
2.7 |
3.3 |
|
|
Gross weight |
3.1 |
3.9 |
|
|
manner of packing |
carton |
||
|
else |
start |
Soft start |
|
|
Cooling way |
Fan cooled |
||
