LED Magnetic Starter

Advantage

> Clean production environment

> Full automatic testing with various tests

> Standardized production process with trained workers

> Low failure ratio and 24-month warranty

> Strong R&D and engineering support

Request a Quote

Product Description

LED Magnetic starter is mainly applied in circuit of AC 50/60Hz,voltage up to 550V for far distance making and breaking circuit and frequency starting and controlling motor.It has the features of small volume,light weight,low power consumption,high efficiency,safe and reliable performance etc.It complies to IEC947-4-1.

Technical Data Sheet

Type	Rated Current(A)	Maximum Power AC3 duty (KW)						Suitable Thermal Relay (A)
Type	Rated Current(A)	220V 230V	380V 400V	415V	440V	500V	660V 690V	Suitable Thermal Relay (A)
LED-09	9	2.2	4	4	4	5.5	5.5	LR2 D1312 LR2 D1314
LED-12	12	3	5.5	5.5	5.5	7.5	7.5	LR2 D1316
LED-18	18	4	7.5	9	9	10	10	LR2 D1321
LED-25	25	5.5	11	11	11	15	15	LR2 D1322 LR2 D2353
LED-32	32	7.5	15	15	15	18.5	18.5	LR2 D2355
LED-40	40	11	18.5	22	22	22	30	LR2 D3353 LR2 D3355
LED-50	50	15	22	25	30	30	33	LR2 D3357 LR2 D3359
LED-65	65	18.5	30	37	37	37	37	LR2 D3361
LED-80	80	22	37	45	45	55	45	LR2 D3363 LR2 D3365
LED-95	95	25	45	45	45	55	45	LR2 D3365
